Description

The Avant A443490 Rotary Hoe Model 1350 is a heavy-duty hydraulic soil cultivation attachment designed for Avant loaders. With a 53-inch working width, it is ideal for seedbed preparation, soil cultivation, rotovating, and landscaping applications. The direct-drive hydraulic motor, adjustable working depth, field roller, and integrated grading rake allow operators to prepare smooth, compacted seedbeds in a single pass while efficiently breaking up soil and burying stones and debris.

Key Specifications

. Model: A443490

. Type: Hydraulic rotary hoe attachment

. Model Size: 1350

. Working Width: 53.1 in (≈1,350 mm)

. Roller Width: 61.0 in (≈1,550 mm)

. Total Width: 67.1 in (≈1,705 mm)

. Working Depth: 2.0–6.0 in (≈50–150 mm), adjustable

. Drive System: Direct-drive hydraulic motor

. Oil Flow Requirement: 40–50 L/min

. Compatibility: Avant loaders with compatible auxiliary hydraulics

. Weight: 606 lb (≈275 kg)

Features

. Direct-drive hydraulic motor delivers efficient soil cultivation.

. Curved blades break up compacted soil for excellent seedbed preparation.

. Vertical grading rake traps stones and debris while burying them beneath the soil surface.

. Rear field roller provides stepless working depth adjustment and compacts the soil after cultivation.

. Adjustable soil scraper blade helps prevent soil buildup during operation.

. Ideal for landscaping, gardening, agriculture, and turf establishment.
