Description:

The Model 127V mid-mount delivers the same professional-quality features of zero-radius maneuverability, comfort, performance and durability of larger Grasshopper models. This small-frame riding lawn mower offers a compact wheelbase that provides easy transport on trailers and fits easily into shops or garages with limited space. Ideal for residential owners or landscapers.

Features:

Heavy-duty Deck:

• Extra-deep, 5.5-inch deck fabricated from heavy-gauge formed steel with a reinforced anvil edge
• Specially designed cutting chambers enhance airflow for superior cut quality
• Easily converts from side discharge to optional Down Discharge™ mulching or PowerVac™ collection
• Sentry™ spindles with massive 8-inch flanges anchored in a 6-bolt pattern for increased strength
• Triple-strength deck formed from double-layered formed steel laminate, keeping blades level for high-quality cuts
• Sentry™ spindle guards shield spindle housing and seal lower bearings from debris

Vigilant Operator Presence System™:

• Standard, low profile operator protection structure (OPS) with an adjustable seatbelt
• Dampened steering levers return to neutral from forward and reverse
• Interlock switches shut down the engine when the operator leaves the seat while PTO is engaged or levers are in drive position
• Shock Impact Reduction System™(SIRS™) for enhanced operator comfort

QuikAjust® Drop Pin Height Adjustment:

• Raise and lower the deck easily with foot pedal and drop pin for precision cutting heights between 1.0 and 5.0 inches

Warranty:

• Commercial Use: 2-year or 500-hour limited warranty covering parts and labor
• Residential Use: 4-year or 500-hour limited warranty: First two years covering parts and labor, last two years covering parts only

Design-Matched Transmission:

• Design-matched, fully hydraulic Parker HTE Series integrated pump-and-wheel-motor transmissions with in-line cooling fans and fine-particle filtration
• No power-robbing gearbox or other wear parts for longer service life
• Best-in-class transmission fluid change interval with no break-in period, reducing costs and maintenance time

Ultimate Operator Station™:

• Deluxe Premium Comfort Seat with coil-spring suspension, padded lumbar support, and sliding adjustment for all-day comfort
• Iso-mounting eliminates vibration, scuff-resistant, breathable CoolTemp Cordura® fabric
• Operational controls positioned for visibility and ease of reach
• ComfortReach™ adjustable Hydra-Smooth™ dual levers return to neutral automatically

Reduced Maintenance:

• Only two Access-Eze™ lubrication points for up to 95% reduced maintenance time
• Self-tensioning belts minimize cost and labor on routine maintenance

Rugged Construction:

• Robotically-welded steel construction for durability
• Centered-bearing design for greater load-bearing capacity
• Tough powder-coated finish for chip and rust resistance

B&S CXi Engine:

• Powerful 810 cc CXi OHV V-Twin engine
• Heavy-duty components enhance power and reliability
• Integrated Cyclonic Air Management System for cleaner performance
• Extended maintenance intervals
• Three-year limited commercial engine manufacturer warranty

Specification:

ENGINE:

• Type/Horsepower/Cylinders: B&S CXi, V-Twin
• Displacement: 49.4 cu. in. (810 cc)
• Lubrication System: Pressure Lube/Filter
• Crankshaft: Vertical
• Cooling System: Air
• Fuel: Gasoline - unleaded
• Fuel Capacity: 6.5 U.S. Gal. (24.6 l)
• Air Cleaner: Integrated, cyclonic air cleaner with 5-step debris management system
• Muffler: Ultra quiet, single, industrial type.

ULTIMATE OPERATOR STATION:

• Seat: Iso-mounted Premium Comfort Seat with high-back, deep-cushioned, Cordura®-covered, padded foldable armrests, padded backrest with lumbar support, and coil-spring suspension
• Suspension: Roomy, iso-mounted footrest with Shock Impact Reduction System™ (SIRS™)
• Console-mounted Instruments: Digital hour meter, parking brake indicator light, ignition switch, choke, and push/pull PTO switch
• Work Lights: Optional - LED

TRANSMISSION & STEERING:

• Type: Design-matched hydrostatic system with in-line cooling fans
• Filtration/Hydro Fluid: Internal field-serviceable filter / CoolTemp Hydro-Max™ fluid
• Speed: 0 - 8.0 mph (0 - 12.9 kph) forward, 0 - 6.0 mph (0 - 9.7 kph) reverse
• Turning Radius: True zero degree, turns within own length with counter-rotating, independently powered drive wheels
• Steering: One- or two-hand operation with adjustable HydraSmooth™ dual levers

TIRE SIZES:

• Drive Wheels - Standard: 20x10x10 turf, 4-ply rated (52" Deck), 20x12.00x10 (61" Deck)
• Front Wheels - All Models: 13x6.50x6; pneumatic with greasable, double-sealed bearings

DIMENSIONS:

• Height (Seat Back): 47.0 in. (119.4 cm)
• Height (Seat Cushion): 29.0 in. (73.7 cm)
• Height (ROPS): 59.0 in. (149.9 cm)
• Length (52" Deck): 75.0 in. (190.5 cm), Length (61" Deck): 78.0 in. (198.1 cm)
• Deck Width (Side Discharge - 52" Deck): 65.5 in. (166.5 cm), Deck Width (Mulch - 52" Deck): 53.5 in.* (135.9 cm)

WEIGHT:

• Uncrated (52" Deck): 830 lbs. (376.5 kg), Uncrated (61" Deck): 880 lbs. (399.2 kg)
• Mulching Package (52" Deck): 29 lbs. (13.2 kg), Mulching Package (61" Deck): 36 lbs. (16.3 kg)
