Description:

The Grasshopper zero-turn 900D 1.3L riding lawn mower provides more power, durability and maneuverability than any mower in its class. This mower is equipped with a fuel-efficient MaxTorque™ Clean Diesel Tier 4 Final-compliant engine that burns less fuel per hour than gasoline or propane mowers. The 900D 1.3L saves landscape contractors time by powering through heavy grass at faster mowing speeds while still delivering a manicured cut thanks to the higher torque output of the diesel engine. Replace the front-mounted deck with a wide choice of grounds maintenance implements for year-round productivity. Use Power Fold® deck lift/electric height adjustment to rotate the deck up for easy cleaning and to fit more mowers on a trailer.

Features:

Quik Converter™ Implement Capability:

• Add or remove implements in minutes without tools with Quik Converter™ Implement System
• Equip your out-front mower with a wide range of tools, including turf cleanup, renovation, and snow removal implements that extend your productivity year-round

Minimal Maintenance:

• Fewer than 10 grease points and easy top-side access to belts and filters
• 1,000-hour transmission fluid change intervals
• Self-tensioning belts minimize cost and labor on routine maintenance

Power Fold® Electric Deck Lift:

• Standard on all Front Mount™ Dura Max® decks, Power Fold® is the zero-turn mower industry's first electric deck lift (introduced in 2004)
• Power Fold® rotates the deck nearly 90 degrees to provide easy access to the underside of the deck for simplified maintenance and mulching package installation, plus space-saving portability and storage
• Adjusts cutting height between 1.25 and 5.0 inches and controls deck lift functions using a single switch

Vigilant Operator Presence System™:

• Standard, low-profile Roll-over Protection System (ROPS) structure with an adjustable seatbelt
• Dampened steering levers and interlock switches for enhanced safety.

Electronic Fuel Gauge/Digital Hour Meter.

Kubota Diesel Engine:

• EPA Tier 4 Final-compliant 77 cu. in. (1.3L), 3-cylinder, liquid-cooled Kubota Clean Diesel engine for smooth, reliable operation.

Design-Matched G3 Transmission:

• Rugged hydrostatic transmission with auxiliary cooling fans and high-torque wheel motors for efficient power transfer.

Wide Stance Single-Fork Tail Wheels for increased flotation and stability.

Hydraulic Lift for maneuverability over soft or uneven ground.

Built for Long Life:

• Robotically-welded, high-grade steel construction with tough powder-coated finish.

LED Work Lights.

USB Ports.

Heavy Duty Deck:

• Extra-deep, 5.5-inch fabricated steel deck.
• Sentry™ spindles for strength.

Warranty:

• Commercial: 3-year unlimited hours.
• Residential: 4-year or 800-hour.

High Temperature Clutch Cut Out.

Ultimate Operator Station™:

• Premium Comfort Seat with coil-spring suspension.
• Iso-mounting to reduce vibration.
• Ergonomic operational controls.

Premier Suspension Seat:

• Adjustable for operators between 100 – 300 lbs.
• Tilting backrest and adjustable armrests.

Specification:

ChatGPT

Engine:

• Type/Horsepower/Cylinders: Kubota MaxTorque™, 3-cyl.
• Displacement: 77 cu. in. (1.3L)
• Lubrication System: Pressure Lube/Filter
• Crankshaft: Horizontal
• Cooling System: Liquid
• Fuel: Diesel - No. 2
• Fuel Capacity: 8 U.S. Gal (30.28 l)
• Air Cleaner: Heavy-duty, remote mounted, cyclonic, dual element air filtration.
• Muffler: Ultra quiet, single, industrial type

DuraMax® Decks:

• Deck: DuraMax
• Mulching Package: Available for 61" and 72" decks

DuraMax® Deck Size:

• 61" Deck: Cutting height range 1.0 to 5.0 in. (2.5 to 12.7 cm)
• 72" Deck: Cutting height range 1.0 to 5.0 in. (2.5 to 12.7 cm)

Construction (Robotic-welded steel):

• Tubular 2.25 in. x 4 in. boxed members with 0.25 in. gussets.
• Formed double thickness hardened steel truss spindle plane.
• Triple-strength upper deck.
• Geometrically engineered design with 7 gauge skirts.

Blades (Tempered, alloy steel):

• 61" Deck: (3) 21 in. (53.3 cm)
• 72" Deck: (3) 25 in. (63.5 cm)

Spindle Assemblies:

• Sentry™ Spindle System.
• Double bearings greasable from top of deck.
• Designed to eliminate fiber wrap.

Spindle Housings:

• 8 in. (20.3 cm)-diameter machined aluminum housing with 6-bolt pattern.

Blade Drive:

• Maintenance-free gearbox with single Kevlar V-belt and idler arm tensioning.

Trimability:

• 61" Deck: 6.25 in. (15.9 cm)
• 72" Deck: 12.25 in. (31.1 cm)

Starter & Electrical System:

• Battery: 12 Volt (maintenance-free)
• Starter: Solenoid shift
• Ignition: Breakerless, diesel quick heat glow plug
• Interlock System: Prevents engine start when PTO clutch is engaged or steering levers are in drive position.

Ultimate Operator Station:

• Seat: Iso-mounted Premium Comfort Seat with coil-spring suspension.
• Suspension: InFrame™ suspension
• Console-mounted Instruments: Low engine oil pressure, alternator, temperature and parking brake warning lights, engine temperature and volt gauges, combination electronic fuel gauge/hour meter, two USB charging ports, ignition, work lights, glow plug and push/pull PTO switches.

Transmission & Steering:

• Type: Rugged, design-matched G3 hydrostatic system.
• Filtration/Hydro Fluid: Integrated, replaceable, high-efficiency, fine-particle filter / Grasshopper CoolTemp Hydro-Max™ fluid.
• Speed: 0 - 11.0 mph (0 - 17.7 kph) forward, 0 - 6.0 mph (0 - 9.7 kph) reverse.
• Turning Radius: True zero degree, turns within own length with counter-rotating, independently powered drive wheels.
• Steering: One- or two-hand operation with adjustable, HydraSmooth™, dual levers.

Brakes & Attachment Drive:

• Brakes: Dynamic braking through hydrostatic transmission.
• Parking Brake: Disc parking brakes, one for each drive wheel.
• Attachment Drive: Telescoping PTO shaft with two high-speed U-joints, Quik-D-Tatch® coupler and heavy-duty electric Mag Stop® blade clutch/brake.

Tire Sizes:

• Drive Wheels - Standard: 24x12.00x12 bar tread, high flotation, 4-ply rated
• Wide Stance Single Fork Tail Wheel: 13x6.50x6 rib tread, pneumatic (2)
• Deck Tires: 11x4.00x5 (flat proof), 4-ply rated for 61" deck, 13x6.50x6 rib tread, pneumatic, 4-ply rated for 72" deck.

Dimensions & Weight:

• Height (Seat Back): 47.0 in. (119.4 cm)
• Height (Seat Cushion): 31.5 in. (80.0 cm)
• Height (ROPS): 69.5 in. (176.5 cm)
• Length (frontmount w/ DuraMax® Deck - Mowing Position): 112.5 in. (285.8 cm) for 61" deck, 120.5 in. (306.1 cm) for 72" deck.
• Length (FrontMount Power Unit + DuraMax® Deck - Folded Up): 94.0 in. (238.8 cm) for 61" deck, 107.0 in. (271.8 cm) for 72" deck.
• Deck Width (Side Discharge): 74.5 in. (189.2 cm) for 61" deck, 85.5 in. (227.3 cm) for 72" deck.
• Deck Width (Mulch): 62.5 in. (158.8 cm) for 61" deck, 73.5 in. (186.7 cm) for 72" deck.
• FrontMount Power Unit Only (Width/Length): 54.5 in. (138.4 cm)/70.0 in. (177.8 cm)
• FrontMount Power Unit (Wheelbase): 54.5 in. (138.4 cm)
• Weight: 1595 lbs. (725.5 kg) for 61" deck, 1695 lbs. (768.8 kg) for 72" deck, 1150 lbs. (521.6 kg) for FrontMount Power Unit Only.
