Description
Description:
The MT225E Series is a high-value and feature rich compact utility tractor. Featuring high-capacity front-loader and three-point hitch is only the start of what this tractor series provides. Additional deluxe features like an electric engaged Independent PTO come standard.
Specifications:
Engine
- Type: 3 Cylinder, liquid-cooled, Diesel, NA, IDI
- Model (Tier 4): Mitsubishi S3L2
- Engine HP (Gross): 24.6
- PTO HP: 19.2
- Rated Speed (RPM): 2,500
- Displacement (cu. in.): 80.4
- Fuel Tank Capacity (gal): 7.4
- Alternator (V-A): 12 – 50
Drive Train
- Transmission: Synchrony shuttle
- No. of Speeds: F12 x R12
- Brakes: Wet, Multi Disc
- Steering: Hydrostatic Power Steering
PTO
- Type: Independent
- Rear (rpm): Standard (540)
Hydraulic System
- Control System: Position
- Implement pump (gpm): 7.9
- Steering pump (gpm): 4.6
- Total flow (gpm): 12.5
- Category, 3 pt hitch: CAT 1
- Hitch Lift Capacity (lb): 1,808
- Remote Valves: Option
Dimension
- Overall Length, Frame to Link (in.): 118
- Wheelbase (in.): 66
- Overall Width with Tires (in.): 54
- Height to Top of ROPS (in.): 88
Tire Size
- Ag Front/Rear: 7 – 14 / 11.2 – 24
- IND Front/Rear: 25 x 8.5 – 14 / 43 x 16 – 20
- Turf Front/Rear: 25 x 8.5 – 14 / 41 x 14 – 20
Weight
- Total Weight without Ballast (lbs.): 2,434
| Width | Weight | Height | Length |
|---|---|---|---|
| 0 Inch | 2434 Pounds | 0 Inch | 0 Inch |
