Description:

Specifications:

Engine

• Type: 3 Cylinder, Liquid-cooled, Diesel, NA, IDI
• Model (Tier 4): MHI
• Engine HP (Gross): 24.6 HP
• PTO HP: 17.1 HP
• Rated Speed (RPM): 2,500 RPM
• Displacement: 80.4 cu. in.
• Fuel Tank Capacity: 10.6 gallons
• Alternator: 12V – 50 Amps

Drive Train

• Transmission Type: HST (Hydrostatic Transmission)
• Number of Speed Ranges: 3
• Brakes: Wet, Multi-disc
• Steering: Hydrostatic Power Steering

PTO

• Type: Independent
• Rear RPM: 540 (Standard)

Hydraulic System

• Control System: Position
• Implement Pump Flow: 7.1 gpm
• Steering Pump Flow: 4.6 gpm
• Total Flow: 11.7 gpm
• Category (3 pt hitch): CAT I
• Hitch Lift Capacity: 1,808 lbs
• Remote Valves: Optional

Dimensions

• Overall Length (Frame to Link): 119 inches
• Overall Width with Tires: 66 inches
• Wheelbase: 66 inches
• Height to Top: 95 inches

Tire Size

• Ag Front / Rear: 7 – 14 / 11.2 – 24
• IND Front / Rear: 27X8.50-15 / 43X16.00-20
• VT Front / Rear: 27X8.50-15 / 43X16.00-20
• Turf Front / Rear: 25X8.50-14 / 41X14.00-20

Weight

• Total Weight (without ballast): 3,007 lbs

Width	Weight	Height	Length
	3007 Pounds		0 Inch
