Description
Description:
Specifications:
ENGINE
- Type: 4-Cylinder, Liquid-Cooled, Diesel, NA (Naturally Aspirated), CRDI (Common Rail Direct Injection)
- Model (Tier 4): YANMAR
- Engine HP (Gross): 42.5 HP
- PTO HP: 35.4 HP
- Rated Speed (RPM): 2,600
- Displacement: 133.6 cu in
- Fuel Tank Capacity: 10.6 gal
- Alternator: 12V – 55 Amps
DRIVE TRAIN
- Transmission Type: Synchro Shuttle
- Number of Speeds: 12 Forward x 12 Reverse
- Brakes: Wet, Multi-disc
- Steering: Hydrostatic Power Steering
PTO (Power Take-Off)
- Type: Independent
- Rear PTO Speed (rpm): 540 (Standard)
HYDRAULIC SYSTEM
- Control System: Position
- Implement Pump Flow: 7.4 gpm
- Steering Pump Flow: 5.0 gpm
- Total Hydraulic Flow: 12.4 gpm
- Category (3-pt Hitch): CAT I
- Hitch Lift Capacity (Hitch End): 1,808 lbs
- Remote Valves: Option
DIMENSIONS
- Overall Length (Frame to Link): 125 in
- Overall Width (with Tires): 66 in
- Wheelbase: 74 in
- Height to Top: 95 in
TIRE SIZE OPTIONS
- Agricultural Front / Rear: 7-14 / 11.2-24
- Industrial Front / Rear: 27X8.50-15 / 43X16.00-20
- VT Front / Rear: 27X8.50-15 / 43X16.00-20
- Turf Front / Rear: 25X8.50-14 / 41X14.00-20
WEIGHT
- Total Weight (without ballast): 3,250 lbs
| Width | Weight | Height | Length |
|---|---|---|---|
| 3250 Pounds | 0 Inch |
