Description
Description:
Specifications:
Engine
- Type: 4-Cylinder, Liquid-Cooled Diesel, Naturally Aspirated, Common Rail Direct Injection (CRDI)
- Model (Tier 4): YANMAR
- Engine Horsepower (Gross): 42.5 HP
- PTO Horsepower: 34.8 HP
- Rated Speed: 2,600 RPM
- Displacement: 133.6 cu. in.
- Fuel Tank Capacity: 11.4 gallons
- Alternator: 12V – 55 Amps
Drive Train
- Transmission Type: Hydrostatic Transmission (HST)
- Number of Speeds: 3 Ranges
- Brakes: Wet, Multi-disc
- Steering: Hydrostatic Power Steering
PTO (Power Take-Off)
- Type: Independent
- Rear PTO Speed: 540 RPM (Standard)
Hydraulic System
- Control System: Position
- Implement Pump Flow: 6.7 gpm
- Steering Pump Flow: 5.0 gpm
- Total Flow: 11.7 gpm
- 3-Point Hitch Category: CAT I
- Hitch Lift Capacity (at Hitch End): 1,808 lbs
- Remote Valves: 1 Pair
Dimensions
- Overall Length (Frame to Link): 125 in.
- Overall Width with Tires: 66 in.
- Wheelbase: 74 in.
- Height to Top: 90 in.
Tire Size
- Ag Tires (Front/Rear): 7 – 14 / 11.2 – 24
- Industrial Tires (Front/Rear): 27 x 8.50 – 15 / 43 x 16.00 – 20
- Versa Turf Tires (Front/Rear): 27 x 8.50 – 15 / 43 x 16.00 – 20
- Turf Tires (Front/Rear): 25 x 8.50 – 14 / 41 x 14.00 – 20
Weight
- Total Weight without Ballast: 3,805 lbs
Width | Weight | Height | Length |
---|---|---|---|
3805 Kilograms | 0 Inch |
