Description:

The MT3 Series provides four different horsepower models featuring both cab and ROPS options. These models are available with gear drive or hydrostatic transmissions. All models feature an ergonomic design making this a truly premium tractor. Hydrostatic cab models feature the all-new Servo HST with Pedal Link.

Specifications:

Engine

• Type: 3 Cylinder, liquid-cooled, Diesel, TC, CRDI
• Model (Tier 4): L3C19-T
• Gross Engine HP: 57
• PTO HP:
• Hydr: 48.4
• Gear: 45.6
• Rated Speed: 2,600 RPM
• Displacement: 114.7 cu. in.
• Fuel Tank Capacity:
• CABIN: 12.4 gallons
• ROPS: 10.6 gallons
• Alternator Output: 12 – 70 V-A

Drive Train

• Transmission: Synchro shuttle / HST
• Number of Speeds:
• Gear: F16 x R16
• HST: 3 Ranges
• Brakes: Wet, Multi-disc

PTO (Power Take-Off)

• Type: Independent
• Rear RPM: 540

Hydraulic System

• Control System: Position/Draft
• Implement Pump: 8.2 gpm
• Steering Pump:
• Gear: 4.1 gpm
• Hydro: 5.5 gpm
• Hydro Cab: 6.8 gpm
• Total Flow:
• Gear: 12.3 gpm
• Hydro: 13.7 gpm
• Hydro Cab: 15.0 gpm
• Category (3 pt hitch): CAT 2
• Hitch Lift Capacity: 2,755 lbs
• Remote Valves: 2 PAIR (1 DETENT, 1 STD)

Dimensions

• Overall Length (Bumper to Link): 133 in.
• Wheelbase: 73.2 in.
• Overall Width with Tires: 62.5 in.
• Height to Top of ROPS:
• ROPS: 95 in.
• Cab: 90 in.

Tire Sizes

• Ag (Front / Rear): 9.5 – 16 / 13.6 – 24
• IND (Front / Rear): 12 – 16.5 / 17.5L – 24
• Turf Tire (Front / Rear): 28 x 8.5 – 15 / 41 x 14 – 20

Weight

• Total Weight without Ballast: 3,869 – 4,446 lbs (cab)

Width	Weight	Height	Length
	3869 Kilograms		0 Inch
