LS TractorSKU: MT774CPS

Contact for package options, pricing, and availability.

GET MORE INFO
Price:
$65,999.00
Stock:
Only 1 unit left

Pickup currently unavailable at Martin's Outdoor Power LLC - Geneva


×

Description

Description:

Features:

  • 24F x 24R Power Shuttle​
  • Standard Air Suspension Seat ​
  • Standard Electric Engaged Independent PTO​
  • Standard Instructor Seat​
  • Standard Interior Power Source​
  • Optional Third Rear Remote​

Specifications:

  • Engine
  • Engine Type: 4 Cylinder, CRDI, Water-cooled
  • Model (Tier 4): F34
  • Engine HP (Gross): 73.7 hp
  • PTO HP: 65.6 hp
  • Rated Speed (RPM): 2,200 rpm
  • Displacement: 206.7 cu. in
  • Fuel Tank Capacity: 30.4 gal
  • Drive Train
  • Transmission Type: Power Shuttle
  • Number of Speeds: 24 x 24
  • Brakes: Wet, Multi-disc
  • Forward Speed: 0.9 – 20.8 mph
  • PTO (Power Take-Off)
  • Type: Independent
  • Rear PTO RPM: 540 / 750 / 1,000 rpm
  • Hydraulic System
  • Control System: Position/Draft
  • Implement Pump: 15.7 gpm
  • Steering Pump: 6.5 gpm
  • Total Flow: 22.2 gpm
  • 3-point Hitch Category: CAT II
  • Hitch Lift Capacity (Hitch End): 7,275 lbs
  • Remote Valves: 3 pairs (Front), 2 pairs (Rear)
  • Dimensions
  • Overall Length (Frame to Link): 152.2 in
  • Wheelbase: 90 in
  • Minimum Overall Width with Tires: 78.7 in
  • Height to Top: 105 in
  • Tire Specifications
  • Front / Rear (R14): FW: 320/85R24, RR: 460/85R30
  • Front / Rear (Ag): F: 11.2-24, R: 16.9-30
  • Weight
  • Total Weight without Ballast: 7,827 lbs
