LS Tractor MT774CPS – 74HP
LS Tractor MT774CPS – 74HP
LS Tractor MT774CPS – 74HP
Roll over image to zoom in Click on image to zoom
LS Tractor MT774CPS – 74HP
LS Tractor MT774CPS – 74HP
LS Tractor MT774CPS – 74HP

LS Tractor MT774CPS – 74HP

LS TractorSKU: MT774CPS

Contact for package options, pricing, and availability.

Price:
$64,999.00
Stock:
Only 1 unit left

Pickup currently unavailable at Martin's Outdoor Power LLC - Geneva


REQUIRES FREIGHT SHIPPING

This item exceeds UPS limits for ground parcel handling and must be shipped via LTL freight. Your order's shipping charges will be custom quoted, and you will be contacted for approval prior to fulfillment.

Questions? Call us or use our web form.

GET MORE INFO


WE SPECIAL ORDER ALL THE TIME!
If this item is currently sold out, call us during business hours, or use this web form, and we will assist you.

ORDER CONSOLIDATION
To provide the best delivery experience, we may consolidate and fill orders via dropship from the manufacturer or authorized vendor.

DISCONTINUATIONS
All parts are subject to manufacturer discontinuation or supersession, without advance notice.

LIMITATION OF LIABILITY
Proper installation and use is the sole responsibility of the buyer. Be safe. Read instructions, follow directions, and work with professional service technicians.

RETURN POLICY

×

Description

Description:

Features:

  • 24F x 24R Power Shuttle​
  • Standard Air Suspension Seat ​
  • Standard Electric Engaged Independent PTO​
  • Standard Instructor Seat​
  • Standard Interior Power Source​
  • Optional Third Rear Remote​

Specifications:

  • Engine
  • Engine Type: 4 Cylinder, CRDI, Water-cooled
  • Model (Tier 4): F34
  • Engine HP (Gross): 73.7 hp
  • PTO HP: 65.6 hp
  • Rated Speed (RPM): 2,200 rpm
  • Displacement: 206.7 cu. in
  • Fuel Tank Capacity: 30.4 gal
  • Drive Train
  • Transmission Type: Power Shuttle
  • Number of Speeds: 24 x 24
  • Brakes: Wet, Multi-disc
  • Forward Speed: 0.9 – 20.8 mph
  • PTO (Power Take-Off)
  • Type: Independent
  • Rear PTO RPM: 540 / 750 / 1,000 rpm
  • Hydraulic System
  • Control System: Position/Draft
  • Implement Pump: 15.7 gpm
  • Steering Pump: 6.5 gpm
  • Total Flow: 22.2 gpm
  • 3-point Hitch Category: CAT II
  • Hitch Lift Capacity (Hitch End): 7,275 lbs
  • Remote Valves: 3 pairs (Front), 2 pairs (Rear)
  • Dimensions
  • Overall Length (Frame to Link): 152.2 in
  • Wheelbase: 90 in
  • Minimum Overall Width with Tires: 78.7 in
  • Height to Top: 105 in
  • Tire Specifications
  • Front / Rear (R14): FW: 320/85R24, RR: 460/85R30
  • Front / Rear (Ag): F: 11.2-24, R: 16.9-30
  • Weight
  • Total Weight without Ballast: 7,827 lbs
